Tsis Siv Neeg Stainless Hlau Bar Circular Sawing Tshuab
Tshuab Qauv
WL-200PZ rau kev txiav cov khoom siv hlau. TCT hniav saw tshuab
TCT Circular Saw tshuab
Khoom duab
Lub siab tsis siv neeg stainless hlau bar ncig saw tshuab yog ib qho cuab yeej ntse tshwj xeeb uas tsim los rau kev ua hlau thiab paub txog nws cov peev xwm ua tau zoo thiab raug txiav. Txawm hais tias nws yog kev tsim khoom loj lossis kev ua haujlwm ntawm tus kheej, lub tshuab saw saw no tuaj yeem ua tau raws li koj xav tau thiab muab kev pabcuam zoo rau koj cov khoom siv hlau txiav.
Lub siab tsis siv neeg stainless hlau bar ncig saw tshuab tau dhau los ua tus pab cuam muaj zog hauv kev lag luam hlau nrog nws cov peev xwm txiav tau zoo thiab meej. Nws tsis tsuas yog txhim kho kev tsim khoom thiab txo cov nqi, tab sis kuj ua kom cov khoom zoo thiab kev nyab xeeb ntawm kev ua haujlwm. Txawm hais tias nws yog kev tsim khoom loj lossis kev ua haujlwm ntawm tus kheej, nws tuaj yeem muab cov kev pabcuam zoo hlau txiav rau koj thiab dhau los ua cov cuab yeej muaj zog rau koj txoj haujlwm.
Cov lus piav qhia ntxaws
Lub tshuab saw saw no txais kev ua haujlwm tsis siv neeg. Koj tsuas yog yuav tsum tau teeb tsa qhov tsis sib xws, thiab lub tshuab tuaj yeem ua tiav kev txiav cov hlau tuav. Tsis muaj kev cuam tshuam phau ntawv yuav tsum tau ua, txhim kho kev tsim khoom thiab kev nyab xeeb ntawm kev ua haujlwm.
Lub voj voog saw tshuab no tau nruab nrog lub cev muaj zog uas tuaj yeem tig tau sai sai kom ua tiav kev txiav ceev thiab txhim kho kev tsim khoom. Ntxiv mus, tsis muaj roj nplua nyeem yuav tsum tau thaum lub sij hawm txiav, txuag nqi ntau lawm.
Factory Display
Peb lub peev xwm yog ib qho ntawm peb cov peev txheej tseem ceeb. Peb muaj ib pab neeg ua haujlwm R & D uas muaj kev paub dhau los thiab muaj peev xwm uas txuas ntxiv tsim cov khoom siv hlau ncig pom tshuab. Peb cov cav tov muaj kev ua haujlwm siab, precision thiab yooj yim ntawm kev ua haujlwm kom tau raws li ntau yam kev xav tau ntawm cov hlau txiav.
Exhibition Zaub
Qhov no hlau ncig saw tshuab exhibition yeej lub siab nyiam ntawm manufacturers. Cov khoom siv nthuav tawm ua haujlwm zoo, ruaj khov thiab txhim khu kev qha, thiab cov tuam ntxhab txaus siab rau nws qhov kev ua tau zoo. Los ntawm kev sib pauv nrog cov kws tshaj lij engineers thiab kev kawm los ntawm kev hais lus, cov tuam txhab tsim khoom muaj kev nkag siab ntau dua ntawm kev siv cov hlau ncig pom cov cav tov thiab txhim kho lawv cov txheej txheem ntau lawm.
| PRODUCT PRAMETERS QHOV TSEEB TSHUAJ TIV THAIV |
||
| Qauv | WL-200XG | |
| Txiav muaj peev xwm | Round bar (mm) | 80~200 |
| Square bar (mm) | 80~150 | |
| Round Tube (mm) | 80~200 | |
| Square tube (mm) | 80~150 | |
| Lub taub hau spindle | TCT superhard ncig saw hniav | φ630t3.4 |
| Spindle lub cev muaj zog (kw) | 30 | |
| Spindle ceev (rpm) | 20~60 | |
| Pub Clamps | Feeding Drive hom | AC Servo Tsav + Pob Ntsia Hlau |
| Feeding Clamp Txoj Kev | Hydraulic Clamped | |
| Trim Ntev (mm) | 10 ~ 99 (Tsis muaj lub taub hau txiav yog xaiv tau) | |
| Remnant Ntev (mm) | 120+ | |
| Ib leeg pub Length (mm) | 10~800 | |
| Tsis siv neeg pub khoom noj | Qhov ntev ntawm cov khoom (mm) | 3000~6000 |
| Hom khoom | Preloading / Hydraulic Lifting | |
| Hydraulic ntaus ntawv | Hom hydraulic twj tso kua mis | Hloov pauv hloov piston twj tso kua mis |
| Hydraulic tsav lub cev muaj zog (kw) | 5.5(4P) | |
| Hydraulic System Rated Siab (MPa) | 7 | |
| Hydraulic Roj Peev Xwm (L) | 120 | |
| Nyhav & Loj | Qhov hnyav (Machine + Rack) (kg) | 9800 |
| Loj (mm) | 8300x3850x2570 | |
